Make drawing pipework faster and easier. Download the blocks, add them to your tool palette and drag the parts you need into your model space to create professional steel pipeline drawings in minutes. It's that simple.

View all the parts in the viewer.

What you get

• Reducers, reducing TEEs, equal TEEs, 90 degree elbows, 45 degree elbows, pipe, sockets and flanges
• Instruction video showing how to add the blocks to your tool palette
• DWG files work with AutoCAD and similar programs
• Sizes from 25mm to 300mm NB (Nominal Bore)
• Dynamic blocks that adjust to your needs
• Every part shows front, top and side views
• Clear English labels on every part
• 121 ready-to-use pipe parts

Why you'll love it

• Save hours of drawing time (I spent 100+ hours creating these)
• Perfect for plumbers, engineers and designers
• Professional looking drawings every time
• No more drawing pipes from scratch
